「快速门电机」工业门-快速门用电机的分类和挑选

「快速门电机」工业门-快速门用电机的分类和挑选




Classification and Selection of "Fast Door Motor" Industrial Door-Fast Door Motor

快速门是现在很多行业都会挑选装置的一种电动门，它能够快速的运转而且还能做成很大的面积，便利大型器械的进出，解决工厂车间器械修理和装置不便利的问题，而门体上也能够开小门，便利平常人员进出，这样就能够不用普通开启整个门体了。




Fast door is a kind of electric door which can be selected in many industries. It can run fast and make a large area to facilitate the entry and exit of large-scale equipment. It can solve the problem of inconvenient repair and installation of equipment in factory workshop. It can also open small doors on the door body to facilitate the entry and exit of ordinary people, so it can not be used. Open the whole door with ordinary.


工业门因为门体通常很大，所以本身重量都很重，再加上运转速度很快，而门体的运转就都靠电机来带动了，所以电机对于快速门来说很重要，下面我们就来看看挑选快速门电机时要考虑哪些事情?




Industrial doors are usually very large, so their weight is very heavy, coupled with the speed of operation is very fast, and the operation of the door body is driven by the motor, so the motor is very important for fast doors. Now let's see what to consider when selecting the motor for fast doors.




「快速门电机」工业门-快速门用电机的分类和挑选




Classification and Selection of "Fast Door Motor" Industrial Door-Fast Door Motor




1.要先考虑电机外观，有直臂式：外表式装置，青铜合金螺杆，享有专利的内部结构，有更少的运动部件;




1. Consider the appearance of the motor first. There are straight arms: exterior device, bronze alloy screw, patented internal structure, and fewer moving parts.



曲臂式：外表式装置，人体工程学相结合，手臂式运转，由铸铝抗剪切曲臂




Crankarm type: Appearance type device, combined with ergonomics, arm type operation, by cast aluminium shear resistant crank arm



地埋式：地埋式装置，很多人的挑选，不影响装置建筑整体风格，隐蔽漂亮




Buried type: buried type device, many people's choice, does not affect the overall style of the installation building, concealed beautiful



2.需考虑门柱大小：




2. The size of the portal post should be considered:



直臂电机：要求门轴的中心到装置柱边缘不大于150MM;




Straight arm motor: The center of the door shaft to the edge of the device column is not more than 150 MM;



曲臂电机：要求门轴的中心到装置柱边缘不大于450MM;




Crankarm motor: the center of the door shaft to the edge of the device column is not more than 450 MM;



地埋电机：对门柱大小没有任何要求，支持任何装置条件。




Buried motor: No requirement for the size of the door post, support any device conditions.



3.考虑使用频率：




3. Consider the frequency of use:



每天开关门超过150次以上选配直流电机，支持频频开启，遇阻反弹;




More than 150 times a day, DC motors are selected to support frequent opening and rebound in case of resistance.



开关150次以下主张选配交流电机，功率微弱，合适重型门，价格更经济，有电机过热保护功用，无遇阻反弹;




Switch 150 times below advocates the selection of AC motor, weak power, suitable heavy door, more economical price, motor overheating protection function, no resistance rebound;

面上现在还有快速平开门电机可选，特别合适特别场所，包含大使馆、特别职能管理机构，有防跟从，防尾随，防闯入功用。




On the surface, there are also fast flat door motor options, especially suitable for special places, including embassies, special function management agencies, with anti-follower, anti-tail, anti-intrusion function.
